Processor & ChipsetNumber of Processors Supported2
Processor & ChipsetProcessor SocketSocket B LGA-4677 Series
Processor & ChipsetProcessor TypeXeon 5400
Processor & ChipsetProcessor(s) SupportedPlatinum 8500
Gold 6500
Silver 4500
Gold 5400
Gold 4310
Gold 2400
MemoryMemory TechnologyDDR5 SDRAM
MemoryMemory StandardDDR5-4800/PCl-5600U
MemoryNumber of Total Memory Slots32
ControllersSATASATA III, 0, 1, 10
ControllersNVMe8x NVMe drives
Display & GraphicsGraphics Controller ManufacturerASPEED
Display & GraphicsGraphics Controller ModelAST2600 GPU
I/O ExpansionsPCI Express7x PCle 5.0 x8 via Slots (supports 4x double-wide cards)
Drive BaysHot-swap24x 2.5" Hot-swap Drive Bays
Interfaces/PortsTotal Number of USB 2.0 Ports5x USB 2.0 (Front)
3x USB 3.0 (Rear)
1x USB 2.0 (BMC, Type-A)
Interfaces/PortsNumber of SATA Interfaces8
Interfaces/PortsLAN2x RJ45 1GBASE-T
1x RJ45 Management Port
Interfaces/PortsNetwork Video1x VGA Connector
Power DescriptionColorBlack
Power DescriptionForm FactorRack-mountable
Power DescriptionRack Height4U
Power DescriptionHeight7.00"
Power DescriptionWidth17.2"(depth)
Power DescriptionDepth27"
