Supermicro MBD-X14DBI-T Dual Xeon E2 E-ATX
The Supermicro MBD-X14DBI-T is a high-performance E-ATX server motherboard designed for enterprise and data center applications. It features dual Socket E2 (LGA-4710) sockets supporting Intel Xeon 6700/6500 series processors, up to 4TB of DDR5 ECC RDIMM memory, and up to 1TB of DDR5-8000 ECC MRDIMM memory with supported P-core CPUs. It also provides PCIe 5.0 expansion, dual 10GbE networking, and an ASPEED AST2600 BMC for remote management.
Specification | Details |
|---|---|
Model | Supermicro MBD-X14DBI-T |
Form Factor | E-ATX |
CPU Support | Dual Socket E2 (LGA-4710), Intel Xeon 6700/6500 Series |
Memory | 16 DIMM Slots, DDR5 ECC RDIMM / MRDIMM |
Maximum Memory | Up to 4TB RDIMM / 1TB 8000MT/s MRDIMM |
PCIe Expansion | 4× PCIe 5.0 x16, 2× PCIe 5.0 x8 |
M.2 | 2× M.2 PCIe 5.0 x4 |
Networking | Dual Broadcom BCM57416 10GbE + Dedicated 1GbE IPMI |
BMC / Management | ASPEED AST2600 BMC |
Security | TPM 2.0 |
